Circuit Protection

Siemens: SDV7 Medium-Voltage Outdoor Distribution Circuit Breakers Are Now UL Listed
| |

Siemens: SDV7 Medium-Voltage Outdoor Distribution Circuit Breakers Are Now UL Listed

Siemens is proud to announce that its SDV7 family of medium-voltage outdoor distribution circuit breakers has been verified by UL Solutions to meet the requirements found in the relevant industry standards (IEEE Standard C37.04 and IEEE Standard C37.09, respectively). Additionally, through rigorous tests, UL Solutions determined that these circuit breakers meet the safety requirements of IEEE Standard C37.20.7, “Guide for Testing Switchgear Rated Up to 52 kV for Internal Arcing Faults.” A testament to the quality and reliability of Siemens’ SDV7 circuit breakers, the UL verification provides a reliable benchmark for product quality and performance.

TA35/TA36: Thermal-Magnetic Circuit Breakers from SCHURTER
| | |

TA35/TA36: Thermal-Magnetic Circuit Breakers from SCHURTER

September 24, 2024 SCHURTER has a long tradition with circuit breakers. In addition to their thermal release (bimetal), the classic TA35 and TA36 are now optionally equipped with an additional magnetic module, which promises reliable protection within milliseconds in the event of very high overcurrent (short circuit). Thermal Circuit BreakersCircuit breakers are usually designed according…

WAGO: 1-Channel Electronic Circuit Breaker (ECB) with 24 VDC Input Voltage
| |

WAGO: 1-Channel Electronic Circuit Breaker (ECB) with 24 VDC Input Voltage

Among WAGO’s electronic circuit breaker offerings is a space-saving ECB with one channel that reliably and safely trips in the event of an overload and short circuit on the secondary side. This ECB has a switch-on capacity of >50,000 μF, enables the use of an economical, standard power supply, and minimizes wiring via two voltage outputs while maximizing commoning options on both input and output sides (e.g., commoning of the output voltage on 857 amd 2857 Series devices).

Mersen: MDC15D Series DC Distribution Fuses
| | |

Mersen: MDC15D Series DC Distribution Fuses

Mersen is excited to announce the MDC15D series, the latest addition to Mersen’s MDC DC Distribution fuse family. The MDC15D series offers full range 1500VDC protection up to 65A in a 20x65mm ferrule mount design. With a high interrupting rating of 50kA, the MDC15D series is ideal for EV charging applications for both AC and DC currents. It also provides protection to cabling and bus bar. Mersen’s MDC DC Distribution fuses help customers achieve the ultimate protection for today and tomorrow and let system integrators and OEM manufacturers easily select fuses for the protection of DC distribution in a variety of applications.

RS Adds Lincoln Industrial and MTE Corporation as New Industrial Lubrication and Power Quality Solutions Suppliers
| | | | | | | | | | |

RS Adds Lincoln Industrial and MTE Corporation as New Industrial Lubrication and Power Quality Solutions Suppliers

RS has recently added two new suppliers to its expansive line card: Lincoln Industrial, an SKF brand, and MTE Corporation. Lincoln Industrial, an SKF brand, is a global supplier of industrial lubrication equipment, handheld lubrication tools, and accessories backed by a combination of more than 300 years of research and development experience dedicated to reducing friction. MTE Corporation is a global supplier of simple, robust power quality solutions. Formed in 1982 by combining three well-established and -respected companies that specialized in different magnetics and transformer designs.

SCHURTER: FPAC RAIL – 3-Phase DIN Rail-Filter
| | | | |

SCHURTER: FPAC RAIL – 3-Phase DIN Rail-Filter

SCHURTER launches a new FPAC Rail 3-phase filter series for DIN rail mounting. Thanks to the slim housing (44 mm), it takes up very little space on the mounting rail in the control cabinet. The single-stage filter is available with standard or high attenuation. A metal base plate ensures an excellent ground connection to the rail. Space is almost always at a premium in control cabinets for industrial applications in the 3-phase range (e.g. motor drives, control systems). SCHURTER addresses this problem with a complete new filter design that is just 44 mm in width.

Eaton: Arc Flash Relay
| |

Eaton: Arc Flash Relay

Eaton’s Arc Flash Relay (EAFR) provides reportedly unmatched switchgear protection. This relay reduces arc flash energy by quickly clearing the current feeding the arc. The sensitive light inputs with current permissive detection identify low power phase to ground arc faults. The EAFR works to prevent faults in medium and low-voltage switchgear, and the factory-installed Arc Flash Relay modules and sensors allow for simple integration into electrical assemblies.

Panduit: G6 PDU Series Boosts Panduit PDU Offerings
| | |

Panduit: G6 PDU Series Boosts Panduit PDU Offerings

Panduit is pleased to announce the global release of its G6 PDU Series. The innovative G6 line marries the best-in-class form factor of the G5 Series with an upgraded intelligence card to bring faster performance along with new functions and cybersecurity improvements to customers. Among the main features of the G6 PDU is its low-profile design that saves rack space while increasing airflow. The device, which provides 128 times the memory of the G5, also offers incredible outlet density and the ability to daisy chain up to 32 PDUs.

Phoenix Contact: QUINT HP AC UPS for High-Energy Applications
| |

Phoenix Contact: QUINT HP AC UPS for High-Energy Applications

High-power applications can run more reliably when backed by the new QUINT HP AC UPS from Phoenix Contact. The uninterruptible power supply (UPS) includes Phoenix Contact’s UPS IQ technology and battery management system, so technicians can always access important data for quick troubleshooting. Previously, applications between 1.5 and 2.5 kVA required connecting two UPS modules and four or more batteries in parallel. The modular QUINT HP AC UPS saves space and reduces costs for larger applications. The panel-mounted platform has a battery capacity range of 7-200 amp hours and can monitor up to five battery units.

Mersen: 1500VDC HelioProtection PV Fuse Range Expansion
| |

Mersen: 1500VDC HelioProtection PV Fuse Range Expansion

Mersen is excited to announce the extension of its line of new 1500VDC HelioProtection 20x65mm PV fuses. With the addition of 63A and 65A fuses in both ferrule and crimp cap models, Mersen HP15P fuses are now available in ampere ratings from 20A-65A. Mersen’s HP15P Series 1500VDC HelioProtection fuses are designed specifically to meet higher amperage demands of today’s PV circuits. The fuses have a 20x65mm form factor and are designed to handle the harsh cyclical loads and thermal conditions of the highest amperage applications.

Phoenix Contact: New Addition to CAPAROC Electronic Circuit Breaker System
| | | | |

Phoenix Contact: New Addition to CAPAROC Electronic Circuit Breaker System

The newest addition to the CAPAROC circuit breaker system from Phoenix Contact can communicate with PLCs via EtherNet/IP, one of the most common industrial protocols in the U.S. The CAPAROC system collects power data and signals so that users can respond to an issue before a failure occurs. The EtherNet/IP power module ensures consistent communication and control of the circuit breaker modules that protect the end devices.

SCHURTER: Power Dissipation in Power Entry Modules
| | | |

SCHURTER: Power Dissipation in Power Entry Modules

If different electrical components are combined in an appliance inlet to form a power entry module, the individual power losses and temperature deratings of all components involved must be carefully taken into account in order to ensure long-term safe operation. Power entry modules (PEMs) consist of a combination of different components for the safe power supply of devices. In addition to the IEC appliance inlet connector, mains switches, fuseholders or circuit breakers and filters can be integrated.

WAGO: New 4- and 8-Channel Electronic Circuit Breakers (ECBs) – Configuration, Control and Monitoring for a Large Number of Channels
| |

WAGO: New 4- and 8-Channel Electronic Circuit Breakers (ECBs) – Configuration, Control and Monitoring for a Large Number of Channels

Six new products are joining WAGO’s selection of ECBs. WAGO’s 4- and 8-channel electronic circuit breakers will soon come equipped with a communication interface. These devices allow a choice among IO-Link, Modbus RTU and Manchester protocol for configuration, control and monitoring. Combining them with a controller makes it possible to read out current values, adjust tripping thresholds, configure behavior in limiting ranges, set an individual pre-warning and switch and reset channels individually.

Schneider Electric: EvoPacT ANSI, the Next Generation of Digital MV Circuit Breakers
| | |

Schneider Electric: EvoPacT ANSI, the Next Generation of Digital MV Circuit Breakers

March 18, 2024 The next generation, natively digital CB for panel builders and users of MV switchgear in Primary Distribution applications. Includes scalable connectivity, with integrated sensors, IoT and a HMI that enables remote digital operation from outside of the arc flash zone. Anticipate and detect abnormal conditions with 24/7 condition monitoring and best-in class…

LUTZE: Introducing IO-Link Gateway
| | | |

LUTZE: Introducing IO-Link Gateway

The IO-Link Gateway provides a wide range of valuable functions, such as advanced energy management, monitoring status information like flowing current or operating voltage, as well as remote control and parameterization of all connected LOCC-Box-Net modules. By incorporating a gateway into DC applications, each LOCC-Box-Net module can be configured and controlled individually or collectively as an entire set.
