EATON Wiring Manual Library Now Available for All EPLAN Customers

January 5, 2021

Eaton’s electrical business has deep regional application expertise in power distribution and circuit protection; power quality, backup power and energy storage; control and automation; life safety and security; structural solutions; and harsh and hazardous environment solutions. Through end-to-end services, channel and an integrated digital platform & insights Eaton is powering what matters across industries and around the world, helping customers solve their most critical electrical power management challenges.

Eaton’s mission is to improve the quality of life and the environment through the use of power management technologies and services. Eaton provides sustainable solutions that help their customers effectively manage electrical, hydraulic, and mechanical power – more safely, more efficiently, and more reliably.

Wiring Manual

The classic from Eaton now also with eBUILD from EPLAN

The EATON Wiring Manual has been an integral part of the education and professional life of anyone involved with electrical switchgear for decades.

It includes an extensive collection of detailed circuit diagrams for Eaton’s industrial switchgear. Many examples of applications of EATON equipment are presented in detail, allowing easy and quick application of the equipment. The reference to the relevant standards, daily required formula and tables complete the content.

Digital content is playing an increasingly important role today. Eaton have therefore decided to offer the first contents of the Wiring Manual in EPLAN under eBUILD. The first application they have implemented is a motor starter for a three-phase motor. For starting the motor a power contactor DIL is selected. The PKZ motor-protective circuit-breaker can also be selected for short-circuit and overload protection, or the ZB overload relay for separate overload protection. After selecting the desired devices the eBUILD macro generates the corresponding circuit diagram and the bill of material. The article links into the Data Portal are also added here.

EATON offers a full range of products for switching and protecting motors. Motor contactors up to 1600A and the corresponding motor protection devices are available in a wide range. Fuses and preassembled motor starter combinations as well as a wide range of accessories are also available for the product range.

Important Links Bar.jpg

https://www.eplanusa.com/company/news/view/eaton-wiring-manual-library-now-available-for-all-eplan-customers/
