HELUKABEL: Durable Connection Cables for Flexible Monitors


August 23, 2022

In a southern Germany hospital, 225 patient beds were equipped with new flexible monitors, making the screen position easy to change. However, due to poor quality cabling, the monitors did not withstand the stresses associated with everyday use. HELUKABEL took a closer look at the problem and found a solution by supplying a much stronger cable with greater durability that is typically applied to machine control panels.

Monitors that can be tilted and rotated are found in many different applications such as operating terminals in mechanical and plant engineering, in control centers and control rooms in manufacturing and logistics facilities, and even in medical equipment for operating rooms and hospital recovery rooms. The daily use of these devices exposes them to certain stresses and strains. For instance, their cabling is particularly susceptible to damage due to constant tensile stresses.

A hospital manager who equipped around 225 beds with new patient monitors that could be tilted experienced this problem. For many patients, the TV screen is an important distraction in the recovery process and an easy way to pass time. It is very frustrating when a device does not work due to a defect.

The problem was the manufacturer-supplied cables were of inferior quality. With an outer diameter of just .13 inches (3.3 millimeters), an inner conductor of only AWG30 (0.05 mm²), and the absence of shielding, the connection cables could not withstand the daily stresses and strains associated with everyday life at the hospital. Due to the tensile forces during use, cables and plugs broke after a very short time period and needed to be replaced again and again by facility management. This resulted in a considerable and unnecessary waste of time and money.

A TENSILE STRENGTH THAT IS ROUGHLY THREE TIMES AS HIGH

The hospital management turned to HELUKABEL to find a solution. The supplier of cables and wires recommended the HELUKAT500 IND EXTRAFLEX patch cable as a new connection cable. This cable originates from the mechanical engineering sector, where it is used in control panels with adjustable screens, among other applications. With a significantly higher and thus standard-compliant cable cross section of AWG26 (0.14 mm²), it offers around three times the tensile strength of the previously used cable. In addition, the shielding, which has the purpose to improve electromagnetic compatibility (EMC), reinforces the cable’s tensile strength. With this product, damage and equipment malfunctions are rarer, which reduces the need for repairs and maintenance. Thanks to its excellent flexibility, the cable is also ideal for medical overhead supply units or other mobile applications in various industries.


For more information, visit HERE.
