ARBOR: New EmSMK-i2403 SMARC 2.0 CPU Module


October 3, 2022

ARBOR Technology has recently announced the release of the ARBOR EmSMK-i2403, based on Intel Atom x7-3950, x5-3940, x5-E3930 Processors which are low power, high performance, and cost effective. The board sizes are defined: 82mm x 50mm with SMARC 2.0 Standard.

Multiple I/O Interface

EmSMK-i2403 features 2 x USB 3.0, 6 x USB 2.0 and 4 x PCIex1 lanes. As to storage, Users are able to choose the SATA type HDD or eMMC for the storage. With an extended range operating temperature of -20 to 85˚C, the EmSMK-i2403 can be suitable for harsh environments, as the result, it is suitable for automation, medical, IoT, and transportation applications.

Wide Expansion

With SDIO, I2S, I2C, and SMBus, EmSMK-i2403 can reduce latency and broaden the device communication path for multiple applications.

I2C is a serial communication protocol that can connect multiple peripherals. It is a master-slave communication in which ARBOR can connect and control various slaves from a single master. It is widely used in embedded industrial PC. EmSMK-i2403 also provides 4 x PCIe lanes, SDIO, and SMBUS. Then users can more devices for different applications. EmSMK-i2403’s attributes make it an ideal solution for applications in the automation and transportation industries.


Features

  •    –   Onboard Intel Atom E3950, E3940, E3930 processor
  •    –   Support 4 x PCIex1 lanes
  •    –   Support one Ethernet
  •    –   Support 1 x eDP, 1 x HDMI, 1 x DP++
  •    –   Extended Range Operating Temperature: -20 ~85˚C


https://www.arbor-technology.com/en/new/New-ARBOR-EmSMK-i2403-SMARC-2-CPU-Module

More Information



Post Views: 569
