Banner Engineering: LC25T In-Line Touch Switch

March 27, 2023

The LC25T In-Line Touch Switch is a sealed, capacitive touch switch that can be connected in-line with many types of DC devices for on/off and PWM (Pulse Width Modulation) dimming control. With a 4-amp output capacity, it can even control the largest of Banner’s DC lights. Its touch interface and colored visual status indication make the LC25T easy to use.

LC25T Touch Switch Key Benefits

Sealed for Harsh Environments

Banner’s LC25T is a unique industrial switch that can be used to solve challenging applications. LC25T features excellent immunity to false triggering by water spray, oils, and other foreign materials. Its ergonomic design allows it to be actuated with bare hands or gloves for simple operation with the touch of a finger. Its overmolded design is IP65/67/68 rated, making it ideal for wet environments. Durable M12 in-line connection and custom brackets make it easy and quick to install without impacting existing application framework.

Customizable Intensity Control

With its low-profile and sleek design, the LC25T is an easy-to-use interface for controlling a wide range of DC devices. LC25T has the capability to dim lights using PWM output, allowing users to define their preferred states. Customize intensity levels by touching and holding the switch to set your preferred intensity, or double tap to return to 100% intensity. It remembers the last saved state so employees can quickly return to their preferred intensity. Similarly, if power to the device is lost, the switch will return to the last intensity it was set to once power has been restored.

Visual Feedback for Status Indication

The LC25T effectively communicates status to users with green, blue, and red colors to indicate different states. When the connected device is off, the LEDs indicate red. When the device is on or at full intensity, the LEDs indicate green. When the connected device is on and in any intermediary PWM state, the LEDs indicate blue, which corresponds to the PWM percentage. Communication is visual, easy to see, and understand, even in busy environments.
