EPLAN Data Portal Update September 2022

PB 27 Eplan logo 400, Data Portal

September 8, 2022

Since September 8th, in addition to updated data, EPLAN are very pleased to announce the following new additions:

New manufacturer catalogs

  •    –   Technische Alternative RT GmbH – 27 new data sets with universal controllers and measuring instruments

Updates and new data

  •    –   ABB LTD – 200 updated data sets with protection devices and converters
  •    –   Balluff GmbH – 5 new and 2 updated data sets with plugs, sensors, switches and pushbuttons
  •    –   CHANGSHU SWITCHGEAR MFG.CO., Ltd. – 1,296 new data sets with generals
  •    –   Cognex Corporation – 6 new data sets with field distribution devices
  •    –   Danfoss Drives A/S – 34 new data sets with converters
  •    –   Eaton Industries GmbH – 1,721 new and 920 updated data sets with sensors, switches and pushbuttons, signal devices, power switchgear and resistors
  •    –   EPSON – 6 new and 51 updated data sets with electrical engineering – special items, housing accessories and internal extensions
  •    –   Fuji Electric FA Components Co., Ltd. – 3,157 new data sets with sensors, switches, pushbuttons and signal devices
  •    –   ifm electronic gmbh – 6 new and 1 updated data set with PLC and sensors
  •    –   Igus GmbH – 46 new data sets with cables
  •    –   IMI Precision Engineering plc – 322 new data sets with accessories
  •    –   Lenze SE – 6 updated data sets with PLC
  •    –   Murrelektronik GmbH – 12 new data sets with voltage sources and generators
  •    –   Omron Europe B.V. – 6 new and 701 updated data sets with pushbuttons
  •    –   Pilz GmbH & Co. KG – 8 new and 46 updated data sets with cables, plugs, amplifiers, controllers, connection splicers / line connectors, PLC, sensors, switches and pushbuttons
  •    –   Rockwell Automation – 728 updated data sets with pushbuttons, relays and power supplies
  •    –   Rockwell Automation (NFPA Data) – 728 updated data sets with pushbuttons, relays and power supplies
  •    –   Schneider Electric SA – 5 updated data sets with measuring instruments and test devices
  •    –   Schrack Technik GmbH – 1,145 updated data sets with protection devices, relays and contactors
  •    –   SEW-EURODRIVE GmbH & Co. KG – 44 new and 1 updated data set with general and PLC
  •    –   Siemens AG – 41 updated data sets with PLC
  •    –   TE Connectivity – 1 updated data set with one plug
  •    –   Tekima S.r.l. – 1228 new and 4508 updated data sets with housing accessories, external extensions and cables
  •    –   Weidmueller Group – 4 new data sets with terminals


  •    –   1 new manufacturer
  •    –   24 updated manufacturer
  •    –   7,975 new data sets
  •    –   9,079 updated data sets
  •    –   23 deleted data set
  •    –   9,785 new parts with EDS
  •    –   In total 681,825 parts with EDS
  •    –   In total 250 manufacturers with EDS parts
  •    –   In total 1.310.803 data sets live in EDP
