Hammond Manufacturing: Hole Plugs


March 29, 2022

Introducing Hammond Manufacturing’s hole plugs, designed to seal unused pushbutton holes, conduit openings and knockout holes against dust, oil and water, with a standard pushbutton size of 30.5mm and a mini pushbutton size of 22.5mm. These hole plugs come in two variations; steel and stainless steel.

Steel Hole Plug

  •    –   Available in 12 sizes.
  •    –   Finished in 2 color options – ANSI 61 gray or RAL7035 Light Gray
  •    –   Oil resistant gasket.
  •    –   Secured with an 10-24 x 0.55″ threaded stud and plated wing nut.

Stainless Steel Hole Plugs

  •    –   Available in 8 sizes.
  •    –   Finished in brushed natural 304 stainless steel finish.
  •    –   Oil resistant gasket.
  •    –   Secured with an 10-24 x 0.55″ threaded stud and plated wing nut.


https://www.hammfg.com/electrical/products/accessories/hp
