EPLAN Data Portal Update 2 November 2022

PB 27 Eplan logo 400, Data Portal

November 21, 2022

Since November 16th, in addition to updated data EPLAN are very pleased to announce the following new additions:

New manufacturer catalogs

  •    –   Pneumax – 6,240 new data sets with limit switchers, cylinders, sub-plates and valves

Updates and new data

  •    –   Banner Engineering Corporation – 16 new data sets with saftey controllers
  •    –   Cognex Corporation – 40 new data sets with bar lights
  •    –   Danfoss Drives A/S – 2 new and 13 updated data sets with converters
  •    –   Eaton Industries GmbH – 493 new and 81 updated data sets with power switchgears
  •    –   Festo SE & Co. KG – 56 new and 12 updated data sets with cables, valves and sub-plates
  •    –   ifm electronic gmbh – 5 new and 15 updated data sets with sensors, switches and pushbuttons
  •    –   ILME SPA – 125 new and 4 updated data sets with plugs and connection splicer/line connectors
  •    –   JUMO GmbH & Co. KG – 11 new data sets with amplifiers, compact controllers and controllers
  •    –   Leuze electronic GmbH + Co. KG – 40 new data sets with sensors
  •    –   Panduit Corp. – 94 new data sets with measuring instruments, test devices, voltage source and generators, cable ducts, housing accessories, internal extensions, routing accessouries and user-defined rails
  •    –   PHOENIX CONTACT GmbH & Co. KG – 1,626 new and 530 updated data sets with general, terminals and miscellaneous
  •    –   Pilz GmbH & Co. KG – 7 new data sets with generals and PLC
  •    –   Rittal GmbH & Co. KG – 9 new and 983 updated data sets with sensors, switches, pushbuttons, terminals, lights, motors, electrical engineering – special items, miscellaneous, housing enclosures, housing accessories, external extensions, internal extensions, 19-inch module technology, user-defined rail and routing accessories
  •    –   Rockwell Automation – 9 new and 251 updated data sets with terminals, PLC and cables
  •    –   Rockwell Automation (NFPA Data) – 11 new and 249 updated data sets with terminals, PLC and cables
  •    –   Schneider Electric – 7 new data sets with PLC
  •    –   SEW-EURODRIVE GmbH & Co. KG – 3 new and 9 updated data sets with converters
  •    –   Siemens AG – 204 new and 2 updated data sets with labels and PLC
  •    –   NanJing Solidot Electronic Technology – 141 new data sets with PLC
  •    –   WAGO GmbH & Co. KG – 11 new and 83 updated data sets with terminals, cross-connectors and labeling for terminal blocks


  •    –   1 new manufacturer
  •    –   20 updated manufacturer
  •    –   9,152 new data sets
  •    –   2,232 updated data sets
  •    –   80 deleted data set
  •    –   8,565 new parts with EDS
  •    –   In total 730,001 parts with EDS
  •    –   In total 265 manufacturers with EDS parts
  •    –   In total 1,354,814 data sets live in EDP
