CUI Devices: New PTN16 Series Rotary Potentiometer Series Offers Single or Dual Gang Options

July 31, 2023

CUI Devices’ Motion & Control Group recently announced the introduction of a new rotary potentiometer series offering single or dual gang models as well as dual gang options with an on-off switch.

The PTN16 series is housed in a 16.5 mm package with shaft lengths of 15, 20, 25, or 30 mm and D-cut or knurled shaft styles.

Ideal for control inputs for electronic circuits and audio control applications, these models feature resistance ratings from 1 to 2000 kΩ, a rotational life of 10,000 cycles, and a variety of terminal configurations.

These 16.5 mm rotary potentiometers carry linear, logarithmic, and reverse logarithmic tapers, a 0.125 W power rating, and a 300-degree mechanical angle. The PTN16 series further features through hole mounting, center detent options, and an operating temperature range from -10 to 75°C. The PTN16 models are available immediately with prices starting at $0.97 per unit at 300 pieces through distribution.
