Lemo Push-Pull Medical Connectors

REDEL SP Connector

May 12, 2020

      REDEL SP Connectors from Lemo



Lemo has expanded its plastic push-pull connector offering to better serve medical applications. The REDEL SP connectors offer an ergonomic grip and a variety of colours to enhance usability.

The latch sleeve is recessed into the connectors body ensuring greater shock resistance. The outer shell in proprietary sulfone PPSU material (FDA approved) enables extensive sterilisation cycles and high chemical resistance.

The use of a rectangular insert conveniently provides a larger area for higher contact density. Contact configurations are available in solder, crimp and print options.

These circular plastic connectors are especially adapted for applications such as medical instrument devices, automotive and test & measurement.

The complete connector can be easily assembled from spare parts (even the contact configuration) offering good flexibility in stock keeping. This product is ideally suited to be paired with Northwire’s robust USP Class VI silicone cable alternative, BioCompatic cable.



  • Patented Push-Pull system
  • Increased resistance to shock
  • Sterilisable
  • Solder, crimp and print contacts
  • 4 to 22 contacts
  • Gray, black or white outershell
  • Colour coding: red, gray, white, black, green, blue, yellow
  • Several keying options
  • 8 shell styles
  • Blind mating, 100% scoop proof
  • Ergonomic design
  • Temp. range -50°C to 170°C
  • Qualified for electrostatic discharge: IEC 60601-1 (15kV)
  • IP 50



More information on the REDEL SP connector

REDEL SP Connector brochure
